Product Details

SKF Double Row Angular Contact Ball Bearing 3204/3205/3206/a/Atn9/2z 2RS1/Tn9/Ztn9/Mt33/C3

Brand Name SKF
Model Number 3204/3205/3206/a/Atn9/2z
Min.Order Quantity 1 pcs
Price Negotiable

Product Features

SKF 3204/3205/3206/a/Atn9/2z bearing Size Chart (mm/inches)

Bore TypeCylindrical Bore
EnclosureDouble Seal
ConfigurationSingle Row
Weight0.039 kg
d17 mm
D35 mm
B10 mm
Fillet Radius/Chamfer0.3 mm
Dynamic Load Rating6,000 N
Static Load Rating3,250 N
Limiting Speed - Grease14,000 rpm
Factor fo14.3
Radial Clearance0.011 to 0.025 mm
da (min)19 mm
Da (max)33 mm
ra (max)0.3 mm

SKF Double Row Angular Contact Ball Bearing 3204/3205/3206/a/Atn9/2z 2RS1/Tn9/Ztn9/Mt33/C3

SKF Double Row Angular Contact Ball Bearing 3204/3205/3206/a/Atn9/2z 2RS1/Tn9/Ztn9/Mt33/C3 Cad Models
